Buttweld fittings are pipe fittings designed to be welded directly to the ends of pipes using a butt weld. They are used to connect pipes, change direction, branch off, or reduce pipe size, and are typically found in industrial applications where a strong, leak-proof connection is required.

Shyam Metal and Alloys are compression type, Double ferrule tube fittings. The Double ferrules optimize sending and tube gripping function to provide excellent leak + tight connection. Variety of end connections-: Male & Female NPT, BSPP, BSPT, ISO tapered pipe ends. Used in Control Systems, Process and Instrumentation, Industrial Equipment. For Various Industries Such as, • Petroleum Process Plants. • Chemical Process Plants. • Chromatography. • Oil & Gas Industries. • Power generation Plants. • Pulp paper Machinery. • Refineries. Tube sizes :- 1/16”OD TO 2” OD, 2 MM TO 50 MM OD Thread :- NPT BSP BSPT, UNF Pressure ratings :- 6000PSI FOR S.S, 300/ 1000/ 3000PSI FOR BRASS Forms :- Tube to Tube – Straight, Elbow, Tee, Cross, Bulk Head, Male Stud, Male Elbow, Male tee, Female Connector, Female Straight, Elbow, Tee, Positional Elbow, Tee (swivel), Tube closure, Plug, Cap, Weld Connector, Nut, Ferrule Set. Instrumentations :- Air Header( 6Way / 8Way/ 10Way / 12Way & Customized), Manifold-Vlaves (2 Ways Manifold, 3ways Manifold, 5ways Manifold), Condensate Pot (customized), Thermo-well, Pressure Gauges, Temperature Gauges, Temperature Sensors, Material :- Stainless Steel, Inconel, Monel, Hastelloy, Duplex Steel, Copper Alloys, High Nickel Alloys.

Standard Specification for Forged Fittings Range : 15 NB to 100 NB x 2000# to 9000# Form : Socket weld/Threaded – Elbow, Tee, Cross, Reducer, Coupling, cap, Hex Nipple, Hex Plug, Round Plug, Square Plug, Bushing, Union, Weldolet, Threadolet, Sockolet, Elbolet, Nipolet, Flageolet, Latrolet, Sweepolet etc Material of Construction in Forged Fittings ◍ Stainless Steel Forged Fitting Specifications Grades: ASTM A182 & ASME SA182 GR F201, F202, F301, F302, F304, F304L, F309, F310, F316, F316L, F316LN, F316Ti, F317L, F321, F347, 405, 409, 410, 420, 430, 440C, F904L ◍ Duplex Stainless Steel Forged Fitting Specifications Grades: ASTM A182 & ASME SA182 GR 2205 (F51, S31803 / F60, S32205), SMO254 (F44, S32154), 2507 (F53, S32750 / F55, S32760), Ferralium 255 (F61 S32550 etc ◍ Carbon Steel Forged Fitting Specifications Grades: ASTM A105 / A350 Gr. LF2, LF3, ASTM A694 – F42, F46, F48, F50, F52, F56, F60, F65, F70. ◍ Alloy Steel Forged Fitting Specifications Grades: ASTM A182 & ASME SA182 GR F1, F5, F9, F11, F12, F22, F91 ◍ High Nickel Alloy Forged Fitting Specifications Grades:ASTM B564 / A182 GR 200 (N02200), 201 (N02201), Alloy 20 (F20, N08020), 600 (N06600), 601 (N06601), 625 (N06625), 718 (N07718), 800 (N08800), 800H (N08810), 800HT (N08811), 825 (N08825), 904L (N08904), 400 (N04400), 500 (N05500), C726 (N10276), C4 (N06455), C22 (N06022), C2000 (N06200), X (N06002), B2 (N10665), B3 (N10675). ◍ Alloy 20 Forged Fitting Specifications Grades: ASTM B462 & ASME B462 GR Alloy 20 (N08020) ◍ Titanium Forged Fitting Specifications Grades: ASTM B381 & ASME B381 GR F2, F5 (Ti6AI4V), F7 ◍ Copper & Copper Alloy Forged Fitting Specifications. Grades:ASTM B122, B171, B466, B467 Commercial, ETP, OFE, CuNi 90/10 (C70600), CuNi 70/30 (C71500), Brass, Naval Brass, Aluminium Bronze, Admiralty Brass.

Socket weld fittings are used to join pipes, valves, or flanges by inserting the pipe into a recessed portion of the fitting and securing it with a fillet weld. They are commonly used in applications where a high-pressure, leak-proof connection is required, and are often preferred for smaller diameter piping.

Shyam Metal and Alloys are compression type, Double ferrule tube fittings. The Double ferrules optimize sending and tube gripping function to provide excellent leak + tight connection. Variety of end connections-: Male & Female NPT, BSPP, BSPT, ISO tapered pipe ends. Used in Control Systems, Process and Instrumentation, Industrial Equipment. For Various Industries Such as, • Petroleum Process Plants. • Chemical Process Plants. • Chromatography. • Oil & Gas Industries. • Power generation Plants. • Pulp paper Machinery. • Refineries.

Forged Fittings are used for associating or connecting pipes, pimps, valves & other equipments to create a piping system below the size of 2 or 4 inches in diameter. There are mainly two types of forged fittings called socket-weld fittings which are connected to pipes by fillet welds and second one is threaded fittings in which the pipe is screwed onto the fittings. Forged Fitting joints are made by bolting together two Forged fittings with a gasket between them to give a seal.

Nickel & Copper Alloy Range : 15 NB UP TO 100 NB IN 2000 LBS , 3000 LBS , 6000 LBS & 9000 LBS , 150 LBS , 250 LBS. Form :Socket Weld Fittings : Elbow 90 Deg , Cross , Tee , Elbow 45 Deg , Coupling , Half Coupling & End Cap. Nickel Alloy: ASTM / ASME SB 564 UNS 2200 ( NICKEL 200 ) ,UNS 4400 (MONEL 400 ) , , UNS 8825 INCONEL (825) , UNS 6600 (INCONEL 600 ) , UNS 6601 ( INCONEL 601 ) , UNS 6625 (INCONEL 625) , UNS 10276 ( HASTELLOY C 276 ) ASTM / ASME SB 160 UNS 2201 (NICKEL 201 ), ASTM / ASME SB 472 UNS 8020 ( ALLOY 20 / 20 CB 3 ). Copper Alloy : ASTM / ASME SB 61 UNS NO. C 92200 & ASTM / ASME SB 62 UNS NO. C 83600. ASTM / ASME SB 151 UNS NO. 70600 , 71500 , C 70600 ( CU -NI- 90/10) , C 71500 ( CU -NI- 70/30) , ASTM / ASME SB 152 UNS NO C 10100 , C 10200 , C 10300 , C 10800 , C 12000, C 12200.

Carbon & Alloy Steel Range : 15 NB UP TO 100 NB IN 2000 LBS , 3000 LBS , 6000 LBS & 9000 LBS , 150 LBS , 250 LBS. Form : Socket Weld Fittings : Elbow 90 Deg , Cross , Tee , Elbow 45 Deg , Coupling , Half Coupling & End Cap. Carbon Steel :ASTM / ASME A105. ASTM / ASME A 350 LF 2 . Alloy Steel : ASTM / ASME A 182 GR F 5, F 9 , F 11 , F 12 , F 22 , F 91.

Stainless and Duplex Steel Range : 15 NB UP TO 100 NB IN 2000 LBS , 3000 LBS , 6000 LBS & 9000 LBS , 150 LBS , 250 LBS. Form : Socket Weld Fittings : Elbow 90 Deg , Cross , Tee , Elbow 45 Deg , Coupling , Half Coupling & End Cap. Stainless Steel : ASTM / ASME SA 182 F 304 , 304L , 304H, 309H, 310H , 316 , 316H , 316L , 316 LN , 317 , 317L , 321 , 321H , 347 , 347 H Duplex Steel: ASTM / ASME SA 182 F 44 , F 45 , F51 , F 53 , F 55 , F 60 , F 61.
